Single Co-Axial Flush Outlet Plate
Specifications:
Material Plastic
Colour White
Connection Screw

Dimensions mm
Subject to technical modifications.
Single gang outlet wall plate with coaxial socket for TV connection.
Order Code   1 10+ 25+
604-020 Single Co-Axial Flush Outlet Plate 1.70 1.36 1.22



1 x Coaxial Outlet Steel Wall Plate
Specifications:
Material Steel
Finish Polished
Terminals Nickel-Plated
Connection Solder
Dimensions 86 x 86 x 20mm
Subject to technical modifications.
Flush mount steel wall plate with a coaxial socket for TV connection. This style of steel outlet plate matches our range of AV steel wall plates.
Order Code   1 10+ 25+
062-463 1 x Coaxial Outlet Steel Wall Plate 3.00 2.70 2.40



Double Co-Axial Flush Outlet Plate
Specifications:
Material Plastic
Colour White


Dimensions mm
Subject to technical modifications.
Single gang outlet wall plate with two coaxial sockets for TV connection. Supplied with fixing screws
Order Code   1 10+ 25+
604-030 Double Co-Axial Flush Outlet Plate 1.76 0.97 0.87



TV / FM (Diplexer) outlet plate
Specifications:
Material Plastic
Colour White


Dimensions mm
Subject to technical modifications.
Single gang outlet wall plate for TV and FM radio signals. Designed to separate UHF and FM signals from a mast head mixer, transmitted down the same lead. Supplied with fixing screws.
Order Code   1 10+ 25+
604-035 TV / FM (Diplexer) outlet plate 2.30 1.12 0.92



1 x 'F' Socket Outlet Steel Wall Plate
Specifications:
Material Steel
Finish Polished
Terminals Nickel-Plated
Connection Solder
Dimensions 86 x 86 x 20mm
Subject to technical modifications.
Flush mount steel wall plate with an F-connector for satellite connection. This style of steel outlet plate matches our range of AV steel wall plates.
Order Code   1 10+ 25+
062-465 1 x 'F' Socket Outlet Steel Wall Plate 4.62 4.16 3.70



2 x 'F' Sockets Wall Plate
Specifications:
Material Steel
Finish Polished
Terminals Nickel-Plated
Connection Solder
Dimensions 86 x 86 x 20mm
Subject to technical modifications.
Flush mount steel wall plate with two F-connectors for satellite connection. This style of steel outlet plate matches our range of AV steel wall plates.
Order Code   1 10+ 25+
062-466 2 x 'F' Sockets Wall Plate 3.32 2.99 2.66



Co-Axial / Satellite Flush Outlet Plate
Specifications:
Material Plastic
Colour White


Dimensions mm
Subject to technical modifications.
Single gang outlet wall plate with a coaxial socket for TV signals and F type socket for Satellite. Supplied with fixing screws
Order Code   1 10+ 25+
604-045 Co-Axial / Satellite Flush Outlet Plate 2.88 1.92 0.96



Coaxial and 'F' Socket Wall Plate
Specifications:
Material Steel
Finish Polished
Terminals Nickel-Plated
Connection Solder
Dimensions 86 x 86 x 12mm
Subject to technical modifications.
Flush mount steel wall plate with F-connector for satellite and coaxial socket for TV connection. This style of steel outlet plate matches our range of AV steel wall plates.
Order Code   1 10+ 25+
062-467 Coaxial and 'F' Socket Wall Plate 3.16 2.84 2.53



Single Surface Co-Axial Outlet
Specifications:
Material Plastic
Colour White


Dimensions mm
Subject to technical modifications.
Single surface outlet with coaxial socket for TV connection.
Order Code   1 10+ 25+
098-012 Single Surface Co-Axial Outlet 1.10 0.77 0.65



Double Surface Co-Axial Outlet
Specifications:
Material Plastic
Colour White


Dimensions mm
Subject to technical modifications.
Double surface outlet with two coaxial sockets for TV connection. One signal spit between sockets.
Order Code   1 10+ 25+
098-015 Double Surface Co-Axial Outlet 1.68 0.84 0.67
