Toggle Switches

10A SPDT Toggle Switch
Specifications:
Contact Arrangement SPST
Connection Screw
Rating

10A@250VAC

15A@125VAC
Panel Cut out 12mmØ
Dimensions 27 x 19 x 53mm

Standard toggle switch with single pole contacts and chrome toggle. Supplied with two fixing nuts, locking washer and on/off plate.
Order Code   1 10+ 25+
218-025 10A SPST On - Off Toggle Switch 1.02 0.91 0.82



10A SPST Toggle Switch
Specifications:
Contact Arrangement SPDT
Connection Screw
Rating

10A@250VAC

15A@125VAC
Panel Cut out 12mmØ
Dimensions 19 x 29 x 53mm

Standard toggle switch with single pole contacts and chrome toggle. Supplied with two fixing nuts and locking washer.
Order Code   1 10+ 25+
218-026 10A SPDT On - On Toggle Switch 1.07 0.97 0.86



Specifications:
Contact Arrangement SPDT
Connection Screw
Rating

10A@250VAC

15A@125VAC
Panel Cut out 12mmØ
Dimensions 20 x 33 x 47mm

High quality standard toggle switch with single pole change over contacts and chrome toggle. Supplied with two fixing nuts and locking washer.
Order Code   1 10+ 25+
218-511 High Quality 10A SPDT On - On Toggle Switch 2.67 2.50 2.34



10A SPDT Toggle Switch
Specifications:
Contact Arrangement SPDT
Connection Screw
Rating

15A@125VAC
Panel Cut out 12mmØ
Dimensions 16 x 29 x 53mm

Chrome toggle switch with single pole change over contacts, with centre off position. Supplied with two fixing nuts and locking washer.
Order Code   1 10+ 25+
218-027 10A SPDT On - Off - On Toggle Switch 1.07 0.97 0.86



10A DPDT Toggle Switch
Specifications:
Contact Arrangement DPDT
Connection Screw
Rating

10A@250VAC

15A@125VAC
Panel Cut out 12mmØ
Dimensions 29 x 32 x 53mm

Standard toggle switch with double pole change over contacts. Supplied with two fixing nuts and locking washer.
Order Code   1 10+ 25+
218-028 10A DPDT On - On Toggle Switch 1.35 1.22 1.08



Specifications:
Contact Arrangement DPDT
Connection Screw
Rating

6A@250VAC

10A@125VAC
Panel Cut out 12mmØ
Dimensions 20 x 34 x 53mm

Standard chrome toggle switch with double pole change over contacts and centre off position. Supplied with two fixing nuts, locking washer and ON/OFF identification plate. (Low Voltage Applications Only)
Order Code   1 10+ 25+
218-039 10A DPDT On - Off - On Toggle, Low voltage 1.22 1.09 0.97



10A DPDT Toggle Switch
Specifications:
Contact Arrangement DPDT
Connection Screw
Rating

10A@250VAC

15A@125VAC
Panel Cut out 12mmØ
Dimensions 29 x 32 x 53mm

Standard toggle switch with double pole change over contacts. Available as centre off or biased (Sprung loaded) to return to off in both directions. Supplied with two fixing nuts and locking washer.
Order Code   1 10+ 25+
218-029 10A DPDT On - Off - On Toggle Switch 1.33 1.20 1.07
218-030 10A DPDT (On)-Off-(On) Toggle Switch 1.35 1.22 1.08



Specifications:
Contact Arrangement DPDT
Connection Screw
Rating

10A@250VAC

15A@125VAC
Panel Cut out 12mmØ
Dimensions 20 x 33 x 58mm

High quality standard toggle switch with double pole change over contacts and chrome toggle. Supplied with two fixing nuts and locking washer.
Order Code   1 10+ 25+
218-513 High Quality 10A DPDT On - On Toggle Switch 3.26 3.06 2.85
