Crimp Terminals

3.0mm (6BA) Ring Crimp - Red Insulated 3.0mm (6BA) Ring Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 3.7mm Ring crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-037 3.7mm (6BA) Ring Crimp - Red Insulated 0.80 0.56
135-030 3.0mm (6BA) Ring Crimp - Blue Insulated 0.80 0.26



3.5mm (4BA) Ring Crimp - Red Insulated 3.5mm (4BA) Ring Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 4.3mm Ring crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-043 4.3mm (4BA) Ring Crimp - Red Insulated 0.82 0.57
135-035 3.5mm (4BA) Ring Crimp - Blue Insulated 0.80 0.26



5.0mm (2BA) Ring Crimp - Red Insulated 5.0mm (2BA) Ring Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 5.3mm Ring crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-053 4.3mm (2BA) Ring Crimp - Red Insulated 0.86 0.60
135-050 5.0mm (2BA) Ring Crimp - Blue Insulated 0.80 0.26



6.0mm (0BA) Ring Crimp - Red Insulated 6.0mm (0BA) Ring Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 6.4mm Ring crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-064 6.4mm (0BA) Ring Crimp - Red Insulated 1.04 0.73
135-060 6.0mm (0BA) Ring Crimp - Blue Insulated 0.80 0.33



3.0mm (6BA) Fork Crimp - Red Insulated 3.0mm (6BA) Fork Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 3.7mm Fork crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-137 3.7mm (6BA) Fork Crimp - Red Insulated 0.82 0.57
135-130 3.0mm (6BA) Fork Crimp - Blue Insulated 0.80 0.40



3.5mm (4BA) Fork Crimp - Red Insulated 3.5mm (4BA) Fork Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 4.3mm Fork crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-143 4.3mm (4BA) Fork Crimp - Red Insulated 0.78 0.55
135-135 3.5mm (4BA) Fork Crimp - Blue Insulated 0.80 0.40



5.0mm (2BA) Fork Crimp - Red Insulated 5.0mm (2BA) Fork Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 5.3mm Fork crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-153 5.0mm (2BA) Fork Crimp - Red Insulated 0.82 0.57
135-150 5.0mm (2BA) Fork Crimp - Blue Insulated 0.80 0.43



6.0mm (0BA) Fork Crimp - Red Insulated 6.0mm (0BA) Fork Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 6.0mm Fork crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-160 6.0mm (0BA) Fork Crimp - Red Insulated 0.80 0.32
135-160 6.0mm (0BA) Fork Crimp - Blue Insulated 0.80 0.26



2.8 x 0.8 Male Crimp - Red Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ



Insulated 2.8mm Male Blade crimp terminals available in red size only vinyl cover. (Sold as a pack of 10)
Order Code   1 10+
134-628 2.8 x 0.8 Male Crimp - Red Insulated 0.92 0.64



4.8 x 0.8 Male Crimp - Red Insulated 4.8 x 0.8 Male Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 4.8mm Male Blade crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-648 4.8 x 0.8 Male Crimp - Red Insulated 0.98 0.69
135-648 4.8 x 0.8mm Male Crimp - Blue Insulated 0.80 0.27



6.3 x 0.8 Male Crimp - Red Insulated 6.3 x 0.8 Male Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 6.3mm Male Blade crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-663 6.3 x 0.8 Male Crimp - Red Insulated 0.82 0.57
135-663 6.3 x 0.8mm Male Crimp - Blue Insulated 0.80 0.41



2.8 x 0.8 Female Crimp - Red Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ



2.8mm Female crimp terminals available in red size only vinyl cover. (Sold as a pack of 10)
Order Code   1 10+
134-828 2.8 x 0.8 Female Crimp - Red Insulated 0.78 0.55



4.8 x 0.8 Female Crimp - Red Insulated 4.8 x 0.8 Female Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
4.8mm Female crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-848 4.8 x 0.8 Female Crimp - Red Insulated 0.90 0.63
135-848 4.8 x 0.5mm Female Crimp - Blue Insulated 0.80 0.33



6.3 x 0.8 Female Crimp - Red Insulated 6.3 x 0.8 Female Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
6.3mm Female crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-863 6.3 x 0.8 Female Crimp - Red Insulated 0.96 0.67
135-863 6.3 x 0.8mm Female Crimp - Blue Insulated 0.80 0.37



4.8 x 0.8 Shrouded Female Crimp - Red Insulated 4.8 x 0.8 Shrouded Female Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Fully Insulated 4.8mm Female crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-948 4.8 x 0.8 Shrouded Female Crimp - Red Insulated 0.90 0.50
135-948 4.8mm Shrouded Female Spade Crimp - Blue Insulated 0.80 0.45



6.3 x 0.8 Shrouded Female Crimp - Red Insulated 6.3 x 0.8 Shrouded Female Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Fully Insulated 6.3mm Female crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-963 6.3 x 0.8 Shrouded Female Crimp - Red Insulated 0.80 0.44
135-963 6.3 x 0.8 Shrouded Female Crimp - Blue Insulated 0.80 0.40



6.3 x 0.8 Stackable Crimp - Red Insulated 6.3 x 0.8 Stackable Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Stackable 6.3mm Female/Male Insulated crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-864 6.3 x 0.8 Stackable Crimp - Red Insulated 1.28 0.90
135-864 6.4mm Stackable Crimp - Blue Insulated 0.80 0.26



3.9mm Male Bullet Crimp - Red Insulated 3.9mm Male Bullet Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated Male Bullet crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-539 3.9mm Male Bullet Crimp - Red Insulated 0.90 0.63
135-549 4.9mm Male Bullet Crimp - Blue Insulated 0.80 0.32



4.0mm Female Bullet Crimp - Red Insulated 5.0mm Female Bullet Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated Female Bullet crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-540 4.0mm Female Bullet Crimp - Red Insulated 1.02 0.71
135-550 5.0mm Female Bullet Crimp - Blue Insulated 0.80 0.35



Butt Joint Crimp - Red Insulated Butt Joint Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated Butt joint crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-440 Butt Joint Crimp - Red Insulated 0.96 0.67
135-440 Butt Joint Crimp - Blue Insulated 1.00 0.70



2.0mm Male Pin Crimp - Red Insulated 2.0mm Male Pin Crimp - Blue Insulated
Specifications:
Red Wire Size
Cross Sectional Area 0.25 - 1.65mm²
Diameter 0.55 - 1.4mmØ
Blue Wire Size
Cross Sectional Area 1.04 - 2.63mm²
Diameter 1.44 - 1.82mmØ
Insulated 2mm Pin crimp terminals available in two wire sizes. With colour coded vinyl covers. (Sold as a pack of 10)
Order Code   1 10+
134-520 2.0mm Male Pin Crimp - Red Insulated 0.88 0.62
135-520 2.0mm Pin Crimp - Blue Insulated 0.80 0.26

Single Crimp Terminal Single Crimp Terminal with wires
Specifications:
 Wire Size 2 x 18AWG
Cross Sectional Area 2.5mm²
Diameter 6.5mmØ



Single ended wire crimp terminal, simply twist wires together and crimp. Heat resistant nylon body, ideal for use in 'hot' appliances, lights, heaters etc. (Sold individually or as a pack of 20)
Order Code   1 pack
134-000 Single Crimp Terminal 0.27 3.30
