Die Cast Boxes

2U Aluminium Heat Sink Box Line Drawing
Specifications:
Model R1196
Material Aluminium Alloy
Colour Black

Dimensions 90 x 51 x 100mm
  90 x 51 x 200mm
Weight 221g (100mm Box)
  446g (200mm Box)
2U Aluminium heat sink boxes which have external fins to aid component cooling. Each box has internal guides for locating PCB's (Maximum width 85mm). Internal and external slots which can accommodate M3 nuts used for securing or fastening to ancillary equipment. Available in two lengths, end plates ordered separately if required.
Order Code   1 5+ 10+
402-060 2U Aluminium Heat Sink Box 100mm 2.99 2.69 2.54
402-062 2U Aluminium Heat Sink Box 200mm 5.95 5.36 5.06
402-064 End Plate for 2U Boxes 0.62 0.56 0.53



3U Aluminium Heat Sink Box Line Drawing
Specifications:
Model R1197
Material Aluminium Alloy
Colour Black

Dimensions 105 x 60 x 100mm
  105 x 60 x 200mm
Weight 273g (100mm Box)
  541g (200mm Box)
3U Aluminium heat sink boxes which have external fins to aid component cooling. Each box has internal guides for locating PCB's. Internal and external slots which can accommodate M3 nuts used for securing or fastening to ancillary equipment. Available in two lengths, end plates ordered separately if required.
Order Code   1 5+ 10+
402-065 3U Aluminium Heat Sink Box 100mm 3.68 3.31 3.13
402-067 3U Aluminium Heat Sink Box 200mm 7.36 6.51 6.15
402-069 End Plate for 3U Boxes 0.66 0.59 0.56



Sealed Die Cast Aluminium Enclosures
Specifications:
Material Aluminium Alloy
G102 90 x 36 x 30mm
G104 64 x 58 x 35mm
G106 115 x 65 x 30mm
G111 115 x 65 x 55mm
G113 115 x 90 x 55mm
G115 148 x 108 x 75mm
G1201 171 x 121 x 55mm
G124 222 x 146 x 55mm
Aluminium enclosures for sensitive electronic devices. Suitable for use in commercial and industrial environments. These boxes provide effective EMI and RFI shielding and IP65 (dust- and hose-proof) rating. The lid incorporates a recessed neoprene gasket.
with the mounting holes and fixing screws located outside the sealed area.
Threaded bosses on base and guide slots on the side allow the fixing of PCB's.
Order Code   1 5+ 10+
402-020 G102 Sealed Die Cast Aluminium Enclosure 3.98 3.58 3.38
402-021 G104 Sealed Die Cast Aluminium  Enclosure 4.10 3.69 3.49
402-022 G106 Sealed Die Cast Aluminium Enclosure 5.58 5.02 4.74
402-023 G111 Sealed Die Cast Aluminium Enclosure 8.21 7.39 6.98
402-024 G113 Sealed Die Cast Aluminium Enclosure 9.11 8.20 7.74
402-025 G115 Sealed Die Cast Aluminium Enclosure 15.59 14.03 13.25
402-026 G1201 Sealed Die Cast Aluminium Enclosure 15.92 14.33 13.53
402-027 G124 Sealed Die Cast Aluminium Enclosure 17.79 16.01 15.12
