Small Loudspeakers

64 ohm loudspeaker
Specifications:
Impedance 64Ω
Wattage 0.3W
Frequency Range 300 - 5000Hz
Dimensions 66mmØ



Subject to technical modifications.
64 ohm small general purpose full range loudspeaker, suitable for experimental projects.
Order Code   1 10+ 25+
203-001 64 Ohm Loudspeaker 0.75 0.60 0.54



8 ohm loudspeaker
Specifications:
Impedance 8Ω
Wattage 0.3W
Frequency Range 400 - 4500Hz
Dimensions 66mmØ


Subject to technical modifications.
8 ohm small general purpose full range loudspeaker, suitable for experimental projects.
Order Code   1 10+ 25+
203-012 8 Ohm 0.3W Loudspeaker 66mmØ 1.20 1.08 0.96



1.0W Loudspeaker 77mmØ
Specifications:
Impedance 8Ω
Wattage 1W
Frequency Range 300 - 5000Hz
Magnet Size 12mmØ
Sensitivity 85dB
Dimensions 77mmØ
Subject to technical modifications.
A small general purpose full range 8 ohm loudspeaker, suitable for intercoms, toys and door entry systems.
Order Code   1 10+ 25+
203-019 8 Ohm 1.0W Loudspeaker 77mmØ 1.82 1.64 1.46



2.0W Loudspeaker 78 x 78mm
Specifications:
Impedance 8Ω
Wattage 2W
Frequency Range 300 - 1800Hz
Magnet Weight 2.85oz
SPL 87dB
Dimensions 35 x 78 x 78mm
Subject to technical modifications.
General purpose full range chassis loudspeaker. Suitable for all PA purposes, especially for multiple arrangements in column speakers.
Order Code   1 10+ 25+
203-021 8 Ohm 2.0W Loudspeaker 78 x 78mm 4.95 4.70 4.46



4.0W Elliptical Loudspeaker 153 x 100mm
Specifications:
Impedance 8Ω
Wattage 4W
Frequency Range 135 - 10000Hz
Magnet Weight 85g
Sensitivity 95dB
Dimensions 38 x 105 x 156mm
Weight g
Subject to technical modifications.
General purpose full range elliptical speaker. Suitable for use with small amplifiers and project kits.
Order Code   1 10+ 25+
203-023 8 Ohm 4W Elliptical Loudspeaker 153 x 100mm 3.95 3.56 3.36



6W Elliptical Loudspeaker 125 x 75mm
Specifications:
Impedance 8Ω
Wattage 6W
Frequency Range 130 - 9000Hz
Magnet Weight 85g
Sensitivity 92dB
Dimensions 36 x 77 x 125mm
Weight 260g
Subject to technical modifications.
A full range 8 ohm 6 watt elliptical speaker. Suitable for use with amplifiers or additional speaker for radio or TV.
Order Code   1 10+ 25+
203-025 8 Ohm 6W Elliptical Loudspeaker 125 x 75mm 4.25 3.30 2.64



15W Mylar Loudspeaker 100mm
Specifications:
Impedance 8Ω
Wattage 15W
Frequency Range 210 - 7000Hz
Magnet Weight 225g
Sensitivity 98dB
Dimensions 41 x 102 x 102mm
Weight g
Subject to technical modifications.
A full range general purpose weatherproof speaker. Fitted with a Mylar cone, this makes it suitable for applications in bathrooms, boats or any damp environment.
Order Code   1 10+ 25+
203-027 8 Ohm 15W Mylar Loudspeaker 100mm 5.95 5.10 4.59



20W Loudspeaker 125mmØ
Specifications:
Impedance 8Ω
Wattage 20W
Frequency Range 30 - 18000Hz
Magnet Weight 85g
Sensitivity 91dB
Dimensions 45 x 130mmØ
Weight g
Subject to technical modifications.
A 20 watt mid range closed back driver. Ideal for budget three way speaker systems.
Order Code   1 10+ 25+
203-029 8 Ohm 20W Loudspeaker 125mmØ 5.60 4.48 4.03
