Single Sided Low Cost Copper clad board
Specifications:
Material SRBP



Dimensions Various

Single-sided low cost copper-clad printed circuit board made from SRBP, a paper-based material. This material is easier to drill than epoxy glass fibre and results in longer life for drills and cutting tools.
Order Code   1 5+ 10+
339-113 100 x 160mm Single Sided Copper clad board 0.58 0.52 0.46
339-116 100 x 220mm Single Sided Copper clad board 0.62 0.56 0.50
339-137 160 x 233mm Single Sided Copper clad board 1.34 1.21 1.07
339-167 220 x 233mm Single Sided Copper clad board 1.86 1.67 1.49
339-235 8" x 12" Single Sided Copper clad board 2.22 2.00 1.78



Single Sided Copper Glass Fibre Board
Specifications:
Material SRBP
Board Thickness 1.6mm
Copper 305g/m

Dimensions Various
Subject to technical modifications.
High quality single sided copper clad glass fibre board. It is ideal for use with direct imaging via etch resist transfer or ink pen.
Order Code   1 10+ 20+
339-613 100 x 160mm Single Sided Copper clad board 1.06 0.90 0.80
339-616 100 x 220mm Single Sided Copper clad board 1.49 1.27 1.12
339-637 160 x 233mm Single Sided Copper clad board 2.29 1.95 1.72
339-667 220 x 233mm Single Sided Copper clad board 3.50 2.98 2.63
339-735 8" x 12" Single Sided Copper clad board 3.98 3.38 2.99



Double Sided Copper Glass Fibre Board
Specifications:
Material SRBP
Board Thickness 1.6mm
Copper 305g/m

Dimensions Various
Subject to technical modifications.
High quality double sided copper clad glass fibre board. It is ideal for use with direct imaging via etch resist transfer or ink pen.
Order Code   1 5+ 10+
339-813 100 x 160mm Double Sided Copper clad board 1.09 0.93 0.82
339-816 100 x 220mm Double Sided Copper clad board 1.23 1.05 0.92
339-837 160 x 233mm Double Sided Copper clad board 2.30 1.96 1.73
339-867 220 x 233mm Double Sided Copper clad board 2.90 2.47 2.18
339-935 8" x 12" Double Sided Copper clad board 4.05 3.44 3.04



Single Sided Paper Photoresist board
Specifications:
Material Glass Fibre
Board Thickness 1.6mm
Water Absorption 0.3%
Dielectric (1Mhz) 4.20
Flexural Strength 400.3N/mm² (Length)
Flexural Strength 250.0N/mm² (Width)
Peel Strength 1.9N/mm²
Subject to technical modifications.
An economy pre-sensitised single sided paper composite laminate, offering price and weight advantages over normal glass fibre board. The photo resist and the 1oz/ft² of copper are of the same high quality as our normal single sided glass fibre board, only the construction of the laminate makes it more economical and also easy to cut & drill.
Order Code   1 5+
338-002 4 x 6" Single Sided Paper Photoresist board 1.71 1.54
338-004 6 x 12" Single Sided Paper Photoresist board 4.91 4.42
338-009 9 x 12" Single Sided Paper Photoresist board 7.41 6.92
338-010 10 x 12" Single Sided Paper Photoresist board 9.59 8.63
338-011 12 x 12" Single Sided Paper Photoresist board 9.68 8.71
338-012 12 x 18" Single Sided Paper Photoresist board 13.81 12.43
338-013 12 x 24" Single Sided Paper Photoresist board 18.17 16.35
338-014 18 x 24" Single Sided Paper Photoresist board 28.07 25.26



Double Sided Paper Photoresist board
Specifications:
Material Glass Fibre
Board Thickness 1.6mm
Water Absorption 0.3%
Dielectric (1Mhz) 4.20
Flexural Strength 400.3N/mm² (Length)
Flexural Strength 250.0N/mm² (Width)
Peel Strength 1.9N/mm²
Subject to technical modifications.
An economy pre-sensitised double sided paper composite laminate, offering price and weight advantages over normal glass fibre board. The photo resist and the 1oz/ft² of copper are of the same high quality as our normal double sided glass fibre board, only the construction of the laminate makes it more economical and also easy to cut & drill.
Order Code   1 5+
338-016 4 x 6" Double Sided Paper Photoresist board 2.19 1.97
338-018 6 x 12" Double Sided Paper Photoresist board 5.93 5.63
338-023 9 x 12" Double Sided Paper Photoresist board 9.03 8.13
338-024 10 x 12" Double Sided Paper Photoresist board 11.70 10.53
338-025 12 x 12" Double Sided Paper Photoresist board 11.77 10.59
338-026 12 x 18" Double Sided Paper Photoresist board 16.93 15.24
338-027 12 x 24" Double Sided Paper Photoresist board 22.23 20.01
338-028 18 x 24" Double Sided Paper Photoresist board 33.30 29.97



Single Sided Glass Fibre Photoresist board
Specifications:
Material Glass Fibre
Board Thickness 1.6mm
Water Absorption 0.12%
Dielectric (1Mhz) 4.55
Flexural Strength 530N/mm² (Length)
Flexural Strength 425N/mm² (Width)
Peel Strength 1.95N/mm²
Subject to technical modifications.
High quality single sided board coated with positive working photoresist. The glass fibre laminate is to BS4584 and MILSPEC MIL-P-13949GE GRN. The photoresist is applied by a roller coating process which ensures a particular even layer to a thickness of 5 microns. The photoresist is then high temperature cured which, combined with its tough plastic film covering, results in a durable board which can be handled, guillotined and processed with a high degree of safety.
Order Code   1 5+
337-030 160 x 100mm Single Sided Glass Fibre Photoresist board 2.81 2.53
337-031 203 x 114mm Single Sided Glass Fibre Photoresist board 4.05 3.85
337-032 220 x 100mm Single Sided Glass Fibre Photoresist board 3.83 3.45
337-033 233 x 220mm Single Sided Glass Fibre Photoresist board 7.64 6.88
337-035 233 x 160mm Single Sided Glass Fibre Photoresist board 5.39 4.85
337-002 4 x 6" Single Sided Glass Fibre Photoresist board 2.19 1.97
337-007 6 x 12" Single Sided Glass Fibre Photoresist board 6.56 5.90
337-009 9 x 12" Single Sided Glass Fibre Photoresist board 9.83 8.85
337-010 10 x 12" Single Sided Glass Fibre Photoresist board 12.64 11.38
337-011 12 x 12" Single Sided Glass Fibre Photoresist board 12.87 11.58
337-012 12 x 18" Single Sided Glass Fibre Photoresist board 18.10 16.29
337-013 12 x 24" Single Sided Glass Fibre Photoresist board 24.26 22.64
337-014 18 x 24" Single Sided Glass Fibre Photoresist board 35.10 31.59



Double Sided Glass Fibre Photoresist board
Specifications:
Material Glass Fibre
Board Thickness 1.6mm
Water Absorption 0.12%
Dielectric (1Mhz) 4.55
Flexural Strength 530N/mm² (Length)
Flexural Strength 425N/mm² (Width)
Peel Strength 1.95N/mm²
Subject to technical modifications.
High quality double sided board coated with positive working photoresist. The glass fibre laminate is to BS4584 and MILSPEC MIL-P-13949GE GRN. The photoresist is applied by a roller coating process which ensures a particular even layer to a thickness of 5 microns. The photoresist is then high temperature cured which, combined with its tough plastic film covering, results in a durable board which can be handled, guillotined and processed with a high degree of safety.
Order Code   1 5+
337-040 160 x 100mm Double Sided Glass Fibre Photoresist board 3.12 2.81
337-041 203 x 114mm Double Sided Glass Fibre Photoresist board 4.06 3.65
337-042 220 x 100mm Double Sided Glass Fibre Photoresist board 4.36 3.92
337-045 233 x 160mm Double Sided Glass Fibre Photoresist board 6.24 5.62
337-043 233 x 220mm Double Sided Glass Fibre Photoresist board 9.05 8.15
337-016 4 x 6" Double Sided Glass Fibre Photoresist board 2.17 2.06
337-021 6 x 12" Double Sided Glass Fibre Photoresist board 6.23 5.92
337-023 9 x 12" Double Sided Glass Fibre Photoresist board 9.38 8.91
337-024 10 x 12" Double Sided Glass Fibre Photoresist board 11.83 11.24
337-025 12 x 12" Double Sided Glass Fibre Photoresist board 12.25 11.64
337-026 12 x 18" Double Sided Glass Fibre Photoresist board 21.45 19.31
337-027 12 x 24" Double Sided Glass Fibre Photoresist board 27.23 24.51
337-028 18 x 24" Double Sided Glass Fibre Photoresist board 41.34 37.21



Single Sided Glass Fibre Photoresist board
Specifications:
Material Glass Fibre
Board Thickness 0.8mm
Water Absorption 0.12%
Dielectric (1Mhz) 4.55
Flexural Strength 530N/mm² (Length)
Flexural Strength 425N/mm² (Width)
Peel Strength 1.95N/mm²
Subject to technical modifications.
Glass fibre laminate with a photoresist layer identical to the standard 1.6mm thick board listed above with a board thickness of only 0.8mm. Available in single or double sided.
Order Code   1
337-112 12 x 18" 0.8mm Single Sided Glass Fibre Photoresist board 25.61
337-126 12 x 18" 0.8mm Double Sided Glass Fibre Photoresist board 28.77



Silicon Scrub / Polishing Block
Specifications:
Material Tin Plated


Pin Head 2mmØ
Dimensions 7 x 1mmØ
Subject to technical modifications.
A specially formulated silicone block which cleans, degreases and polishes copper clad boards in one simple operation, no need for any other compounds or water. Used primarily for cleaning copper board prior to applying etch resist ink or photoresist liquids, also suitable to clean etched boards before applying a tin coating.
Order Code   1
501-025 Silicon Scrub / Polishing Block 2.14
