Round Momentary Push Switch - Illuminated Red Round Momentary Push Switch - Illuminated Amber Round Momentary Push Switch - Illuminated Green
Specifications:
Contact Arrangement SPDT
Connection Solder
Rating 1A 250Vac
Panel Cut out 12mmØ
Dimensions 14Ø x 44mm

Subject to technical modifications.
Round illuminated single pole non latching change over switch. The switch is illuminated by a 3Vdc LED which has to be connected to an independent supply.
Order Code   1 10+ 25+
212-702 Round Momentary Push Switch - Illuminated Red 3.06 2.04 1.84
212-704 Round Momentary Push Switch - Illuminated Amber 3.06 2.04 1.84
212-705 Round Momentary Push Switch - Illuminated Green 3.06 2.04 1.84



Square Momentary Push Switch - Illuminated Red Square Momentary Push Switch - Illuminated Amber Square Momentary Push Switch - Illuminated Green
Specifications:
Contact Arrangement SPDT
Connection Solder
Rating 1A 250Vac
Panel Cut out 12mmØ
Dimensions 14 x 14 x 44mm

Subject to technical modifications.
Square illuminated single pole non latching change over switch. The switch is illuminated by a 3Vdc LED which has to be connected to an independent supply.
Order Code   1 10+ 25+
212-722 Square Momentary Push Switch - Illuminated Red 2.68 2.14 1.93
212-724 Square Momentary Push Switch - Illuminated Amber 2.68 2.14 1.93
212-725 Square Momentary Push Switch - Illuminated Green 2.68 2.14 1.93



Round Latching Push Switch - Illuminated Red Round Latching Push Switch - Illuminated Amber Round Latching Push Switch - Illuminated Green
Specifications:
Contact Arrangement SPDT
Connection Solder
Rating 1A 250Vac
Panel Cut out 12mmØ
Dimensions 14Ø x 44mm

Subject to technical modifications.
Round illuminated single pole latching change over switch. The switch is illuminated by a 3Vdc LED which has to be connected to an independent supply.
Order Code   1 10+ 25+
212-712 Round Latching Push Switch - Illuminated Red 3.22 2.15 1.93
212-714 Round Latching Push Switch - Illuminated Amber 3.22 2.15 1.93
212-715 Round Latching Push Switch - Illuminated Green 3.22 2.15 1.93



Square Latching Push Switch - Illuminated Red Square Latching Push Switch - Illuminated Amber Square Latching Push Switch - Illuminated Green
Specifications:
Contact Arrangement SPDT
Connection Solder
Rating 1A 250Vac
Panel Cut out 12mmØ
Dimensions 14 x 14 x 44mm

Subject to technical modifications.

Order Code   1 10+ 25+
212-732 Square Latching Push Switch - Illuminated Red 3.38 2.25 2.03
212-734 Square Latching Push Switch - Illuminated Amber 3.38 2.25 2.03
212-735 Square Latching Push Switch - Illuminated Green 3.38 2.25 2.03
