Cebek Chronometer for BCD Display Modules


Cebek Chronometer for BCD Display Modules
Specifications:
Reference CD-16
Range 24' 59"
Relay 5A
Consumption 60mA
Power Supply 12VDC
Dimensions 96 x 95 x 30mm
Weight 146g
Technical Information > Download the Handbook for full specifications and applications
The Cebek CD-16 module is a chronometer with pre-selection and BCD outputs for Cebek BCD display modules. It can count up/down, start/stop, reset and next. Thanks to the incorporated pre-selector, you can select a time, at the end of this one the chronometer will be stopped, activating the relay output. The relay will only switch off until you operate the reset or deactivate the pre-selection option. The maximum time is 59’ 59’’. The CD-46 allows you to control the 4 displays CD-10, CD-11 and one CD-41. It includes terminals, indication LED's and audible sounder.
This Module can control the following Displays
150mm BCD Red LED Display CD-10
300mm BCD Red LED Display CD-11
150mm BCD Super Bright LED Display CD-28
300mm BCD High Visibility Display CD-29
Screen with 2 Displays CD-40
Screen with Display CD-41
Group Counter CD-46


Related Products::
Power Supply FE-103
Keyboard C-5236


Order Code   Each
CD-16 Cebek Chronometer for BCD Display Modules 44.39
