Microcontrollers

Microchip - PIC12C Series

PIC12C509A-04P
A general purpose microcontroller series featuring: In-Circuit Serial Programming, 400ns Instruction Execution, 33/35 Instruction Set, 8-Bit Timer/counter, Watchdog Timer, 6 I/O Pins, Internal/Crystal Resonator/Resistor-Capacitor Oscillator Support. OTP (One Time Programmable) EPROM (Windowed) type available.



PROM

(bytes)

RAM

(bytes)

Max Osc

Speed

 Vcc

I/O Sink

Current

 Package
508A-04P 512 25 4MHz 3 - 5.5V 25mA 8 Pin DIL
509A-04P 1024 41 4MHz 3 - 5.5V 25mA 8 Pin DIL



Order Code   1+

10+

 25+ 50+
PIC12C508A-04P µ Controller 0.78 0.7056 0.6664 0.588
PIC12C509A-04P µ Controller 0.83 0.7488 0.7072 0.624



Microchip - PIC16C5 Series

PIC16C54C-04P Microcontroller
An advanced microcontroller series featuring: 200ns Instruction Execution, 33 Instruction Set, 8-Bit Timer/counter, Watchdog Timer, Internal/Crystal Resonator/Resistor-Capacitor Oscillator Support. OTP (One Time Programmable) or EPROM (Windowed)



PROM

(bytes)

RAM

(bytes)

Max Osc

Speed



I/O Pins

 Package
PIC16C54C-04P 512OTP 25 4MHz   12 18 Pin DIL
PIC16C54BJW 512PROM 25 20MHz   12 18 Pin DIL
PIC16C54A-04P 1024OTP 25 4MHz   12 18 Pin DIL



Order Code   1+

10+

 25+ 50+
PIC16C54C-04P µ Controller 1.49 1.3392 1.2648 1.116
PIC16C54BJW µ Controller 7.60 6.84 6.46 5.70
PIC16C54A-04P µ Controller 1.58 1.422 1.264 1.106



Microchip - PIC16F Series

PIC16F627-20/IP
Flash EEPROM microcontroller series.



Memory PROM

(bytes)

RAM

(bytes)

Max Osc

Speed



I/O Lines

 Package
PIC16F84-04P 1024Flash 68 + 64 4MHz   13 18 Pin DIL
PIC16F84-10P 1024Flash 68 + 64 10MHz   13 18 Pin DIL
PIC16F627A-I/P 1024Flash 224 + 128 20MHz   15 18 Pin DIL
PIC16F627-20/IP 1024Flash 224 + 128 20MHz   15 18 Pin DIL
PIC16F628A-I/P 2048Flash 224 + 128 20MHz   16 18 Pin DIL
PIC16F876-04SP 8192Flash 368 + 256 4MHz   22 28 Pin DIL
PIC16F877-20P 9192Flash 368 + 256 20MHz   33 40 Pin DIL



Order Code   1+

10+

 25+ 50+
PIC16F84-04P µ Controller 3.14 2.8224 2.6656 2.362
PIC16F84-10P µ Controller 4.16 3.90 3.64 3.38
PIC16F627A-I/P µ Controller 1.95 1.85 1.79 1.71
PIC16F627-20/IP µ Controller 1.95 1.85 1.79 1.71
PIC16F628A-I/P µ Controller 2.13 1.9285 1.862 1.7955
PIC16F876-04SP µ Controller 5.10 4.845 4.59 4.336
PIC16F877-20P µ Controller 5.02 4.7747 4.5234 4.4229



Suitable PIC Programmer VM111 or VM134
